DIN 508 / ISO 299
Muttern für T-Nuten
Material: Stahl Güte 10
RoHS & REACH: konform
Oberfläche: schwarz
DIN 508 / ISO 299 Muttern für T-NutenDIN 508 / ISO 299 Muttern für T-Nuten
DIN 508 / ISO 299 Muttern für T-Nuten
DIN 508 / ISO 299 Muttern für T-Nuten

technische Details, Abmessungen in [mm]
a e h k
5 9 6,5 3
6 10 8 4
8 13 10 6
10 15 12 6
10 15 12 6
12 18 14 7
12 18 14 7
14 22 16 8
16 25 18 9
18 28 20 10
20 32 24 12
22 35 28 14
24 40 32 16
28 44 36 18
32 50 40 20
36 54 44 22
42 65 52 26
48 75 60 30
54 85 70 34
d x a
M 4 x 5 50
M 5 x 6 50
M 6 x 8 50
M 6 x 10 50
M 8 x 10 25
M 8 x 12 25
M 10 x 12 25
M 12 x 14 25
M 14 x 16 10
M 16 x 18 10
M 18 x 20 10
M 20 x 22 10
M 22 x 24 5
M 24 x 28 5
M 27 x 32 1
M 30 x 36 1
M 36 x 42 1
M 42 x 48 1
M 48 x 54 1
