d2 | d3 | h | b | t |
20 | 16 | 5 | 4 | 1,5 |
25 | 20 | 6 | 5 | 2 |
28 | 23 | 6 | 5 | 2 |
30 | 25 | 7 | 5 | 2 |
32 | 27 | 7 | 5 | 2 |
35 | 28 | 8 | 6 | 2,5 |
36 | 30 | 8 | 6 | 2,5 |
40 | 34 | 9 | 6 | 2,5 |
42 | 36 | 9 | 6 | 2,5 |
45 | 38 | 10 | 7 | 3 |
50 | 43 | 10 | 7 | 3 |
50 | 43 | 10 | 7 | 3 |
52 | 45 | 11 | 7 | 3 |
55 | 48 | 11 | 7 | 3 |
58 | 50 | 11 | 8 | 3,5 |
62 | 54 | 12 | 8 | 3,5 |
62 | 54 | 12 | 8 | 3 |
68 | 60 | 12 | 8 | 3,5 |
75 | 67 | 13 | 8 | 3,5 |
75 | 67 | 13 | 8 | 3,5 |
80 | 70 | 13 | 10 | 4 |
80 | 70 | 13 | 10 | 4 |
90 | 80 | 13 | 10 | 4 |
90 | 80 | 13 | 10 | 4 |
95 | 85 | 14 | 10 | 4 |
95 | 85 | 14 | 10 | 4 |
100 | 90 | 14 | 10 | 4 |
100 | 90 | 14 | 10 | 4 |
|
|
d1 |
|
M 8 x 1 |
10 |
M 10 x 1 |
10 |
M 12 x 1,5 |
10 |
M 14 x 1,5 |
10 |
M 16 x 1,5 |
10 |
M 18 x 1,5 |
10 |
M 20 x 1,5 |
10 |
M 22 x 1,5 |
10 |
M 24 x 1,5 |
10 |
M 26 x 1,5 |
10 |
M 28 x 1,5 |
10 |
M 30 x 1,5 |
10 |
M 32 x 1,5 |
1 |
M 35 x 1,5 |
1 |
M 38 x 1,5 |
1 |
M 40 x 1,5 |
1 |
M 42 x 1,5 |
1 |
M 45 x 1,5 |
1 |
M 48 x 1,5 |
1 |
M 50 x 1,5 |
1 |
M 52 x 1,5 |
1 |
M 55 x 1,5 |
1 |
M 58 x 1,5 |
1 |
M 60 x 1,5 |
1 |
M 62 x 1,5 |
1 |
M 65 x 1,5 |
1 |
M 68 x 1,5 |
1 |
M 70 x 1,5 |
1 |
|
