DIN 914 / ISO 4027
Gewindestift mit Innensechskant und Spitze
Material: V2A - AISI 304
RoHS & REACH: konform
Oberfläche: blank
DIN 914 / ISO 4027 Gewindestift mit Innensechskant und SpitzeDIN 914 / ISO 4027 Gewindestift mit Innensechskant und Spitze
DIN 914 / ISO 4027 Gewindestift mit Innensechskant und Spitze
DIN 914 / ISO 4027 Gewindestift mit Innensechskant und Spitze

technische Details, Abmessungen in [mm]
d1 M 2 M 2,5 M 3 M 4 M 5 M 6 M 8 M 10 M 12 M 16
d2 1,5 2 2,5 3 4
SW 0,9 1,3 1,5 2 2,5 3 4 5 6 8

Stück je Verpackungseinheit
l | d1 M 2 M 2,5 M 3 M 4 M 5 M 6 M 8 M 10 M 12 M 16
3 200 200 200
4 200 200 200 200 200
5 200 200 200 200 200 200
6 200 200 200 200 200 200 100
8 200 200 200 200 200 200 100
10 200 200 200 200 200 200 100 100
12 200 200 200 200 200 200 100 100 50
16 200 200 200 200 200 200 100 100 50 25
20 200 200 200 200 100 100 50 25
25 200 200 200 200 100 100 50 25
30 200 200 200 200 100 100 50 25
35 200 200 200 100 100 50 25
40 200 200 200 200 100 100 50 25
45 200 100 100 50 25
50 200 100 100 50 25
60 200 100 100 50 25
70 200 100 50 25
80 100 100 50 25
90 100
100 100 100 50 25
110 100
120 100
l | d1 M 2 M 2,5 M 3 M 4 M 5 M 6 M 8 M 10 M 12 M 16
